eco445CVGE4IO
SVS-Vistek ECO 4IO
| Sensor | Sony ICX445AQA |
| Mono/Color | Color |
| Resolution | 1.2 MP |
| Size (H×V) | 1296 px x 964 px |
| Interface | GigE Vision |
| Sensor Format | 1/3" |
| Pixel Size | 3.75 µm x 3.75 µm |
| Frame Rate | 30 fps |
| List Price |
4 x MOSFET LED driver SVCam-ECO-4IO cameras are master in LED illumination and communication and can control the timing for illumination precisely. 4 power outputs (power switches to ground) and 4 inputs (0-24 Volt) provide a maximum of control. Each output can be configured separately to fit the task and type of illumination. Together with a fully programmable sequencer, new possibilities are made available for your applications.Technical Highlights progressive scan sensor 4 x outputs for direct drive and control of LED lighting up to 120 MB/s data rate GigE Vision and GenICam-Standards compliant Industrial I/O interface for easy Integration large range of Software and Algorithms broadcast-safe
