Show technical details of the camera.
Basler pulse
| Sensor | onsemi AR0134 |
| Mono/Color | Mono |
| Resolution | 1.2 MP |
| Size (H×V) | 1280 px × 960 px |
| Interface | USB 3.0 |
| Sensor Format | 1/3" |
| Pixel Size | 3.75 μm × 3.75 μm |
| Frame Rate | 54 fps |
| List Price | €189.00 |
| Camera Manufacturer | Basler |
| Product Name | puA1280-54um |
| Product Family | pulse |
| Product Line | pulse |
| Camera Category | Area Scan Camera |
| Sensor Vendor | onsemi |
| Sensor | AR0134 |
| Shutter | Global Shutter |
| Sensor Format | 1/3" |
| Sensor Diagonal | 6 mm |
| Sensor Type | CMOS |
| Sensor Size | 4.8 mm × 3.6 mm |
| Resolution (H×V) | 1280 px × 960 px |
| Resolution | 1.2 MP |
| Pixel Size (H×V) | 3.75 μm × 3.75 μm |
| Frame rate | 54 fps |
| Exposure Time | |
| Mono/Color | Mono |
| Spectrum | Visible |
| Quantum Efficiency | % |
| Dark Noise | e¯ |
| Saturation Capacity | ke¯ |
| Dynamic Range | dB |
| Signal-to-Noise Ratio | dB |
| Interface | USB 3.0 |
| Image Data Interface | USB 3.0, nominal max. 5 Gbit/s (SuperSpeed) |
| Pixel Bit Depth | 8 bits 12 bits |
| Synchronization | |
| Exposure Control | programmable via the camera API |
| Digital Input | |
| Digital Output | |
| Power Supply | Via USB 3.0 interface |
| Power Requirements | 1.3 W |
| Housing Type | Box |
| Housing Size | |
| Weight | 60 g |
| Lens Mount | CS-mount |
| Operating Temperature | 0 °C - 50 °C |
| Compliances | CE (incl. RoHS) EAC FCC Class B GenICam KC RoHS UL USB3 Vision |
| Warranty | 3 years |
| Standards |
| Source Link | Basler puA1280-54um |
| Others |
