Show technical details of the camera.
Basler dart E
| Sensor | onsemi AR0521 |
| Mono/Color | Color |
| Resolution | 5.0 MP |
| Size (H×V) | 2560 px × 1920 px |
| Interface | BCON for MIPI |
| Sensor Format | 1/2.5" |
| Pixel Size | 2.2 μm × 2.2 μm |
| Frame Rate | 60 fps |
| List Price | On request |
| Camera Manufacturer | Basler |
| Product Name | daA2500-60mci |
| Product Family | dart E |
| Product Line | dart E |
| Camera Category | Area Scan Camera |
| Sensor Vendor | onsemi |
| Sensor | AR0521 |
| Shutter | Rolling Shutter |
| Sensor Format | 1/2.5" |
| Sensor Diagonal | 7.13 mm |
| Sensor Type | CMOS |
| Sensor Size | 5.7 mm × 4.28 mm |
| Resolution (H×V) | 2560 px × 1920 px |
| Resolution | 5.0 MP |
| Pixel Size (H×V) | 2.2 μm × 2.2 μm |
| Frame rate | 60 fps |
| Exposure Time | |
| Mono/Color | Color |
| Spectrum | Visible |
| Quantum Efficiency | % |
| Dark Noise | e¯ |
| Saturation Capacity | ke¯ |
| Dynamic Range | dB |
| Signal-to-Noise Ratio | dB |
| Interface | BCON for MIPI |
| Image Data Interface | |
| Pixel Bit Depth | 8 bits 12 bits |
| Synchronization | |
| Exposure Control | automatic manual programmable via the camera API |
| Digital Input | 2 |
| Digital Output | |
| Power Supply | 5V DC (via BCON for MIPI interface) |
| Power Requirements | 0.6 W |
| Housing Type | Board Level |
| Housing Size | 17.5 mm x 29 mm x 29 mm |
| Weight | 9 g |
| Lens Mount | S-mount |
| Operating Temperature |
| Compliances | CE (incl. RoHS) EAC FCC GenICam KC MIPI CSI-2 RoHS UL |
| Warranty | 3 years |
| Standards |
| Source Link | Basler daA2500-60mci |
| Others |
